Fully Charged’s latest video features Jonny Smith’s modified Enfield 8000 ECC now called the “Flux Capacitor”. The vehicle beautifully illustrates how far batteries have come in the last few decades. When originally manufactured in 1974, the car was equipped with 300 kg of lead-acid batteries for 96 volts, now Smith equipped his with 145 kg of li-ion batteries for 378 volts.
The video and specs below:
The specs of the original and Jonny’s version:
ORIGINAL ENFIELD 8000 TECH SPEC
BODYSHELL: Handbuilt aluminium two-seater
CHASSIS: Square-section tubular steel space frame
SUSPENSION: Coil-over McPherson strut front, four-link rear axle
MOTOR: 8hp / 6kw / 150amps
WHEELS: 10-inch Mini wheels
BRAKES: Non servo Hillman Imp drums
BATTERIES: 8 x 12v 55-amp hour lead acid batteries
TOP SPEED: 40mph
PERFORMANCE: Erm. Well, 0-30mph in 12.5 seconds
RANGE: 35-55 miles, depending on climate and quantity of hills
WEIGHT: 975kg (a lot for such a midget – over 300kg is batteries)
LENGTH: A mere 2.84m / 112″ (a Mini was 3.05m / 120″)
WHEELBASE: Just 1.725m / 68″ (a Mini was 2.04m / 80.3″)
FUEL: 240v mains Economy Seven
FLUX CAPACITOR ENFIELD 8000 TECH SPEC
BODYSHELL: Restored with new (aluminium) sills and bare metal painted in Lambretta GP ‘Yellow Ochre’ colour, Plastics4Performance Lexan windows, glassfibre moulded bumpers
CHASSIS: Custom Webster Race Engineering roll cage welded to original chassis.
SUSPENSION: AVO adjustable shocks, custom rose-jointed four-link rear suspension with narrowed Ford 9-inch LSD back axle with 6-inch long (!) prop shaft, bolt-on rear wheelie bars, urethane bushes on front A-arms
MOTORS: Twin series-mounted 9-inch DC Current Racing motors with Helwig carbon split brushes, silicone insulation rated for 2000 amps at 170v with a max rpm of 5500rpm. No gearbox. Direct drive.
WHEELS/TYRES: British made Wolfrace slot mag 12×5 fronts with 165/55/12 Yokohamas and 14×7 rear Nitto Extreme NT555R 205/55/14 drag radials
BRAKES: Bespoke front disc conversion with AP Racing Caterham caliper and CNC machined hub carrier by BG Developments, Ferodo pads, American spec Ford drum brake rear.
BATTERIES: ithium-ion Kokam military grade cells originally used as starter and mini-gun batteries for the Bell SuperCobra helicopter, discharge 378v/1600amps in a 10 second pulse. Hyperdrive Innovations BMS (Battery Management System)
TOP SPEED: 120mph (est)
PERFORMANCE: 1000lb ft. 500+hp. 0-60 in sub 4 seconds. Quarter-mile in 12 seconds…or less
RANGE: up to 30 miles (est)
